G502 X PLUS is the latest addition to legendary G502 lineage. Reinvented with our first-ever LIGHTFORCE hybrid switches, LIGHTSPEED pro-grade wireless, LIGHTSYNC RGB, HERO 25K sensor, and more.


Primary Specifications

USB-C Charging
106 grams
Low-friction PTFE feet

PHYSICAL SPECIFICATIONS

Weight: 3.74 oz (106 g)
Height: 5.17 in (131.4 mm)
Width: 1.62 in (41.1 mm)
Depth: 3.12 in (79.2 mm)

Technical Specifications
LIGHTSPEED wireless technology
Up to 5 onboard memory profiles 1Two profiles by default, five by using Logitech G HUB Software available for download at logitechg.com/ghub
PTFE Feet
13 programmable controls
8-zone RGB lighting
USB-C charging port
Battery life 2Battery life may vary based on user and computing conditions
Constant motion 120 hrs (37 hrs RGB on)
TRACKING

Sensor: HERO 25K
Resolution: 100 – 25,600 dpi
Max. acceleration: >40G2
Max. speed: >400 IPS 3Tested on Logitech G240 Gaming Mouse Pad
Zero smoothing/acceleration/filtering

Warranty Information
2-Year Limited Hardware Warranty
Part Number

Black : 910-006160
White : 910-006169


ICON. REINVENTED.

G502 X PLUS is the latest addition to legendary G502 lineage. Redesigned and reinvented with the most innovative gaming technologies, including our first-ever LIGHTFORCE hybrid switches, LIGHTSPEED pro-grade wireless, LIGHTSYNC RGB and HERO 25K Optical Sensor. G502 X PLUS is also POWERPLAY compatible—so it never runs out of power.
Designed with shroud
LIGHTFORCE SWITCHES

Hybrid Optical X Mechanical
Designed with shroud
LIGHTSYNC
RGB

POWER-SAVING PLAY DETECTION
Hero 25 K sensor
LIGHTSPEED Wireless

68% FASTER THAN PREVIOUS GEN

LIGHTFORCE SWITCHES

Breakthrough hybrid optical-mechanical switches achieve higher levels of speed and reliability through optical actuation. Mechanical actuation maintains the crisp, tactile feedback that players love.

LIGHTSYNC RGB
LIGHTSYNC technology enables dynamic full-spectrum lighting with total control of approximately 16.8 million brilliant colors across an 8-LED array. Active play detection automatically turns lighting off when your hand covers it, conserving battery power. Customize it all with G HUB software including media-driven effects and advanced personalization.

LIGHTSPEED Wireless
Pro-grade connectivity, now with an updated protocol achieving 68% faster response rate than the previous generation. With the incredible efficiency of LIGHTSPEED technology, G502 X PLUS also achieves up to 120 hours of battery life with RGB off and 37 hours when RGB is set to always on.

HERO 25K Sensor
Our most advanced gaming sensor achieves sub-micron accuracy with zero smoothing, filtering and acceleration. With superior tracking and smart energy consumption, HERO 25K delivers unrivaled performance, power efficiency and precision.

DUAL-MODE SCROLL WHEEL
Spin the lightened wheel freely in hyperfast mode. Switch with a click to ratcheted mode for precise scrolling. Tilt left and right for two additional, fully programmable controls.

POWERPLAY COMPATIBLE
Keep your G502 X PLUS charged, at rest and at play, with our unique wireless charging solution. POWERPLAY makes dead batteries a thing of the past. Never worry about charging your mouse again.
